PATIENT MONITORING SYSTEM

STERNMED

MACS 30 MONITOR

Macs 30 is a multi parameter monitor offering a variety of applications. It can be used to measure and monitor parameters of SpO2, NIBP, Pulse, TEMP, ECG and RESP. Optional mainstream, sidestream EtCO2 and 1 or 2-Channel IBP monitoring functions are also available.

SPECIFICATION :
1. 15” display TFT Color LCD
2. Standard Configuration ECG, HR, RESP, NIBP, SpO2, PR, TEMP
3. ECG sweeping speed 12.5mm/s, 25mm/s, 50mm/s
4. ECG auto gain control
5. Heart rate range 15-350bpm
6. Spo2 display SpO2 value & waveform pulse rate & histogram
7. Measurement Range of Pulse Rate   30-240 bpm
8. RESP Measurement Method Thoracic Impedance
9. RESP Measurement Range 0-100 bpm
10. TEMP Range 21.0-50.0°C
11. NIBP Measurement is Intelligent Oscillometric method
12. NIBP Unit Display 0-300 mmHg
13. Inflation Time  <10s (typical adult cuff)
14. Deflation Time <2s (typical adult cuff)
15. Alarm setting customized upper & lower limits & auto saved
16. Rechargeable lead-acid battery
